LGP Laser Engraving Machine from China manufacturer

Price:	5000.0~150000.0 USD
Payment Terms:	T/T,L/C
Place of Origin:	Hubei, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: JMSZJJG(3D)-130250DT

Production Capacity: 6500sets/year

Delivery Date: 5 to 15 business days

Laser Type: CO2 RF metal laser tube

keyword: LGP Laser Engraving Machine

Working Area: 1300mmX2500mm working size ...

Format Support: AI, BMP, PLT, DXF, DST, etc...

Means of Transport: Ocean

Packing: Standard wooden case packag...

Application: Laser cutting and engraving...

Brand Name: Golden Laser

Laser Power: 100W /150W / 200W / 300W / ...

Working Table: Strip panel working table

Acrylic LGP Laser Engraving Machine For Light Guide Panel

-- If need laser machines price,videos,specifications,pls send enquiry DIRECTLY to my mail address directly,(not on this platform site) or I can't reply you ASAP.

E.m.a.i.l : lijiao(at)goldenlaser(dot)org

M.o.b.i.l.e : 86.189.86.189.531

W.e.b.s.i.t.e : www goldenl-laser com cn

-- Notice: Pls confirm me below to help us recommend a suitable machine to you asap.

1,Which materila you need to cut or engrave?

2,What is the size and thickness?

3,What is your company and website?

4,Which country will the machine be used?

Laser Technology For Backlight Panels:

LGP(light guide pamel) can be processed with GoldenLaser systems using the JMSZJJG(3D)-130250DT Laser Galvanometer Engraving and X-Y Axis Cutting Machine

Laser Solution Specially For Light Guide Plate Making:

Laser engraving machine has good luminance.It is suitable for making high-brighteness light guide panel light box. It's unnecessary to make mold.Any graphics,lines,grid and stipple can be easily made and modified for revision at any time.

Laser engraved backlight-panels:

Uniform surface lighting thanks to LEDs

Large-scale, slim backlighting is used in a multitude of sectors and the demand for high-luminosity solutions is growing continuously. LEDs (Light Emitting Diodes) are an economical solution and thanks to their durability the ideal illuminant for such applications. Typical examples are large-scale luminous displays for furniture, store fixtures and fair booths, picture frames, citylight posters as well as luminous walls and partitions.

Engraving of surface:

The panels used are made of a light-conducting material such as acrylic, which generates a uniform light source. Even illumination over the whole material surface is vital in this application, whereby the light must be deflected vertically to the surface. A raster is created on the surface during laser engraving so that the light that is fed in via the cut edges is emitted evenly. The arrangement of the raster dots or lines can be optimised via the software. The number and distribution of the raster dots enables targeted control of the luminosity.

GoldenLaser - light guide plate laser engraving/cutting machine is mainly used to engrave/cut grid on light guide plate to reflect light. Ensure the same engrave depth, and the same brightness, Our light guide plate engraving/cutting machine created special to process high end slim light box.

According to the character of light guide plate,GoldenLaser develop a new laser cutting equipment--JMSZJJG(3D)-130250DT Light guide plate laser engraving/cutting machine.It is equipped with professional LGP making software,making the LGP cutting work quick and efficient.

Features of recommend machine JMSZJJG(3D)-130250DT:

1.A fast and precise dot system, greatly enhance the production efficiency of light guide plate lattice point.
2.Dot-making,lineation,enraving and cutting in one operation.
3.Compatible with main design sofrware,and automatically optimize the parameter.
4.Support multiple light-in sides and variety of light-in methods.

JMSZJJG(3D)-130250DT Laser Galvanometer Engraving and X-Y Axis Cutting Machine

Brief introduction:

This laser machine combines two different laser functions together. X-Y Gantry system for large format and high precision cutting; Germany Galvo system for fast and precise engraving. Two systems only share one laser tube and can switch freely. Ball screw transmission ensures the two systems running stable. Galvanometer scanning system for very fast and large pattern engraving. Coherent or Synrad CO2 RF metal laser tube produces high quality laser beam, stable power and long working life. Low use-cost, maintenance-free and high efficiency.

Main Technical Parameter:
Model No.	JMSZJJG(3D)-130250
Laser Type	CO2 RF metal laser tube
Laser Power	100W /150W / 200W / 300W / 400W /500W
Working Area	1300mmX2500mm
Galvo Engraving Area (one time)	400mm×400mm
Working Table	Strip panel working table
Processing Speed	0-360000mm/min
Repeating Location Accuracy	±0.1mm
Motion System	Off-line Servo control system, lead-screw driving
Cooling System	Constant temperature water-chiller
Power Supply	AC220V ± 5% / 50Hz
Format Support	AI, BMP, PLT, DXF, DST, etc.
Working size and laser power can be customized according to requirement.

Application:

light guide plate is widely adopted in advertising ultra-thin light box, sign board, shop showcase due to its even light with features of environmental protection and energy saving.

Applicable Materials:Besides cutting pmma,acrylic,organic glass,plexiglass,perspex for light guide plate,this machine is also can cut wood,plastic,rubber,paper,color paltes,bamboo,metal and more nonmetal materials.

Advertising industry, lighting industry, exhibition industry, decoration, crafts gifts,advertising,package and printing industry etc.
