Saturn Series Roll to Roll Cloth Laser Engraving Machine

Payment Terms:	T/T,L/C
Place of Origin:	Hubei, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: ZJ(3D)-320LD

Production Capacity: 6000sets/year

Delivery Date: 5 to 15 business days

Laser Type: CO2

Means of Transport: Ocean

Packing: Standard wooden case packag...

Application: Laser Engraving

Brand Name: Golden Laser

Saturn Series Roll to Roll Cloth Laser Engraving Machine

Saturn Series Roll to Roll Cloth Laser Engraving Machine

ZJ(3D)-320LD super-wide format roll to roll fabrics engraving & punching machine

Machine Feature

It is especially designed for continuous engraving and punching on home textile. The width of the working table can reach 3200mm.

It adopts triaxial dynamic processing system. It can do engraving, punching and cutting on carpet materials at one time.

It is suitable for large format engraving and greatly increases the quality and added-value of the materials.

It has 300W RF metal laser tube for standard collocation. The processing speed is fast and the effect is precision.

It is equipped with red light positioning device ensuring precise material feeding and processing quality.

5 inch LCD screen CNC operating system supports multiple data transmission mode and can run in offline and online modes.

Technical Parameter

Laser types	CO2 RF metal laser tube
Laser power	300W
Cutting area	3200mm ×not limitation with processing length
Working table	Engraving conveyor working table
Working speed	Adjustable
Repeating location	± 0.1mm
Moving system	Offline mode servo motor control system, 5 inch LCD screen
Cooling system	Constant temperature water chiller
Power supply	AC380V + 5% 50HZ
Format supported	AI, BMP, PLT, DXF, DST etc.
Standard collocation	Auxiliary ladder equipment, fixed top exhaust suction system, red light positioning, roll to roll feeding, rewinding device (servo motor system, position correcting device).
Optional collocation	CO2 RF metal laser tube(400W)

Application Field
It is suitable for engraving and punching on textile,cloth,leather, suede and denim fabrics,carpet for home textile,bedding,curtain,garment and accessories,sofa,automotive interior,upholstery industry etc.
